YORKVILLE

YXL15

YXL15

YXL15

$1,250.00
$1,355.00 $1,250.00
Sale Sold out

YXL 15-inch / 1-inch - 600 Watts - Passive Cabinet

The YXL cabinets use a single driver and 90 x 40 degree horn with 1-inch throat and 1-inch compression driver. Constructed from strong Polypropylene, YXL is poised to uphold Yorkville's reputation for reliability and durability. The cabinets can be positioned upright or used as a monitor wedge.

Features

  • 600 Watts (Program)
  • 8 Ohms
  • 15-inch woofer with 3-inch voice coil
  • 1-inch compression driver
  • 90° x 40° HF dispersion
  • Polypropylene cabinet construction

Specifications

System Type Passive Loudspeaker
Active or Passive Passive
Power Rating (Watts) 600 Watts Program
Sensitivity (dB @1Watt/1m) 98dB
Max SPL (dB) 125dB Continuous
Frequency Response (Hz +/- 3dB) 45 - 16k (Hz +/-3dB)
Dispersion (°H x °V) 90 x 40
Crossover Frequency (Hz) 1.6kHz
HF Horn Integrated into Baffle
LF Driver(s) 15-inch (3-inch voice coil)
Feet Rubber
Bar Handles 2 x Side / 1 x Back
Flying Hardware 2 (Top), 1 (Pull Back)
Optional Flying Hardware Yes
Enclosure Materials Polypropylene, Metal grille
Baffle Material Polypropylene
Grille Powder Coated Steel with Grille Cloth
Other Details Rubber feet on bottom and side with the monitor Wedge
Dimensions (DWH xbackW, inches) 14.75 x 17 x 27.375
Dimensions (DWH xbackW, cm) 37.5 x 43.18 x 70.4
Weight (lbs/kg) 50 / 23
