YORKVILLE
EF12
EF12
SKU:EF12
Regular price
$2,900.00
Regular price
$3,065.00
Sale price
$2,900.00
Unit price
/
per
Couldn't load pickup availability
Elite 12-inch / 3-inch - 600 watts
Building on the market success and positive user reaction to the Elite powered cabinets, Yorkville Sound introduces three new elite passive speakers. Now available in 10, 12 and 15-inch configurations, the passive elites' provide the perfect solution for installations and venues with existing power amps.
Features
- 12-inch Two-way Passive Loudspeaker
- 600 Watts (1200 Watts peak)
- 127dB Peak (124dB Continuous) Max SPL
- 55 - 18k (Hz +/- 3dB)
- Made In Canada
Specifications
| System Type | Two Way |
| Active or Passive | Passive |
| Power Rating (Watts) | 600 Watts (1200 Watts Peak / 300 Watts Continuous) |
| Biampable | No |
| Nominal Impedance (Ohms) | 8 |
| Sensitivity (dB @1Watt/1m) | 97 |
| Max SPL (dB) | 128dB Peak (125dB Continuous) |
| Frequency Response (Hz +/- 3dB) | 55 - 18k |
| Crossover Frequency (Hz) | 1900 |
| Driver Configuration | 12-inch, 3-inch Diaphragm |
| HF Driver(s) | 3-inch Voicecoil (Titanium Diaphragm) |
| HF Horn | ABS plastic custom Waveguide |
| HF Dispersion (°H x °V) | 60x40 |
| HF Protection | 3xSK3 protection bulbs |
| LF Driver(s) | 12-inch (3-inch voicecoil) |
| Inputs - 1/4" Jacks | 2 |
| Inputs - Speakon 4-pin | 2 |
| Bar Handles | 2 |
| Flypoints | 8 x ¼-20 (2 Top, 2 Bottom, 2 Each Side, 2 Pullback) |
| Pole Mount Adapter (1 3/8"-3.5cm) | Yes |
| Enclosure Materials | 15mm (5/8inch) 11-ply Russian Birch |
| Grille | Perforated Metal |
| Covering / Finish | Black Ultrathane Paint |
| Dimensions (DWH xbackW, inches) | 14 x 16 x 25.5 x 9.5 |
| Dimensions (DWH xbackW, cm) | 35.5 x 40.5 x 64.8 x 24 |
| Weight (lbs/kg) | 51 / 23 |
