EF10
Elite 10-inch / 1-inch - 325 watts
Building on the market success and positive user reaction to the Elite powered cabinets, Yorkville Sound introduces three new elite passive speakers. Now available in 10, 12 and 15-inch configurations, the passive elites' provide the perfect solution for installations and venues with existing power amps.
Features
- Ten-inch Two-Way Passive speaker
- 325 Watts (650 Watts Peak / 250 Watts Continuous)
- 127dB Peak (124dB Continuous) Max SPL
- 65 - 20k (Hz +/- 3dB)
- Made in Canada
Specifications
| System Type | Two Way |
| Active or Passive | Passive |
| Power Rating (Watts) | 325 Watts (650 Watts Peak / 250 Watts Continuous) |
| Biampable | No |
| Nominal Impedance (Ohms) | 8 |
| Sensitivity (dB @1Watt/1m) | 99 |
| Max SPL (dB) | 127dB Peak (124dB Continuous) |
| Frequency Response (Hz +/- 3dB) | 65 - 20k |
| Crossover Frequency (Hz) | 2900 |
| Driver Configuration | 10-inch / 1-inch |
| HF Driver(s) | 1-inch throat (1-inch Titanium Diaphragm) |
| HF Horn | ABS plastic custom Waveguide |
| HF Dispersion (°H x °V) | 100x30 |
| HF Protection | 2xSK3 protection bulbs |
| LF Driver(s) | 10-inch (2-inch voicecoil) |
| Inputs - 1/4" Jacks | 2 |
| Inputs - Speakon 4-pin | 2 |
| Bar Handles | 1 |
| Flypoints | 8 x ¼-20 (2 Top, 2 Bottom, 2 Each Side) + 1 Pullback (Back) |
| Pole Mount Adapter (1 3/8"-3.5cm) | Yes |
| Enclosure Materials | 15mm (5/8inch) 11-ply Russian Birch |
| Grille | Perforated Metal |
| Covering / Finish | Black Ultrathane Paint |
| Dimensions (DWH xbackW, inches) | 13 x 13.7 x 20 x 11.1 |
| Dimensions (DWH xbackW, cm) | 33 x 34.8 x 50.8 x 28.2 |
| Weight (lbs/kg) | 42.5 / 19.4 |
